CKGKL Series Dry-Type Air Core Reactor
2.Reactor connected in series with the capacitors suppress harmonic voltage amplification.
3. reduce system waveform distortion .
4.limit inrush currents during capacitor switching.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
CKGKL Series Dry-Type Air Core Reactor
Product Introduction
The CKGKL Series Dry-Type Air Core Reactor represents advanced engineering in power quality solutions for modern electrical systems. This specialized inductive component operates at a rated voltage of 3464.1V and connects in series with capacitor banks to deliver exceptional harmonic suppression and current limiting performance. When you connect this reactor to your power distribution system, it effectively suppresses harmonic voltage amplification while reducing system waveform distortion. The air core design eliminates saturation issues entirely, ensuring consistent performance under all operating conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Rated Voltage | 3464.1V |
| Core Type | Air Core (No Magnetic Core) |
| Insulation Class | Class F (155°C) / Class H (180°C) |
| Cooling Method | AN (Air Natural) |
| Installation | Vertical Mounting |
| Winding Material | Aluminum/Copper Options |
| Encapsulation | Epoxy Resin-Impregnated Glass Fiber |
| Standards Compliance | IEC 60076-6, GB/T 1094.6 |
| Noise Level | <65dB at Standard Distance |
| Weather Protection | UV-Resistant Silicone Paint |
Main Features and Advantages
Perfect Magnetic Linearity: The air core design ensures your reactor maintains constant inductance regardless of current magnitude, even during fault conditions.
Zero Core Losses: Without iron cores, you eliminate hysteresis and eddy current losses, achieving superior efficiency and high Q-factor performance.
Enhanced Safety: The dry-type construction removes risks associated with oil leakage, fire hazards, and environmental contamination concerns.
Robust Mechanical Structure: Multi-layer coaxial cylindrical coil construction withstands extreme electrodynamic forces during short circuits.
Weather Resistance: Specialized surface treatments provide excellent performance in high humidity, salt fog, and industrial pollution environments.
Maintenance-Free Operation: The solid encapsulation design requires virtually no routine maintenance beyond periodic visual inspections.
Practical Applications
Renewable Energy Systems: Your wind and solar installations benefit from harmonic filtering and voltage stabilization when integrating with grid-tie inverters.
Industrial Manufacturing: Heavy industry applications like steel mills and electric arc furnaces rely on these reactors for managing severe harmonic distortion and switching transients.
Power Transmission Networks: UHVDC converter stations utilize these reactors in AC filter banks to ensure stable long-distance power transmission.
Commercial Buildings: Large commercial facilities use these reactors to improve power factor and reduce harmonic pollution in electrical distribution systems.
How It Works
The CKGKL Series Dry-Type Air Core Reactor functions through electromagnetic induction principles without magnetic saturation limitations. When you install it in series with capacitor banks, the reactor creates a tuned circuit that targets specific harmonic frequencies. The air gap design allows magnetic flux to flow freely without core restrictions, maintaining linear inductance characteristics. During capacitor switching operations, the reactor limits inrush currents by providing controlled impedance. This protects your switchgear and extends capacitor life significantly.
Manufacturing Excellence
Our manufacturing process follows strict quality control protocols throughout every production stage. We utilize advanced winding techniques with tension-controlled processes to ensure mechanical stability. The epoxy resin impregnation occurs under vacuum conditions, eliminating air pockets and ensuring uniform insulation properties. Each reactor undergoes comprehensive testing including inductance verification, insulation resistance measurement, and thermal performance validation before shipment.
Why Choose Us
Xi'an Xidian Medium and Low Voltage Electric Co., Ltd. brings decades of expertise in power distribution equipment manufacturing. Our ISO9001, ISO14001, and OHSAS18001 certifications demonstrate our commitment to quality, environmental responsibility, and safety standards. We provide comprehensive technical support from initial system design through long-term operation. Our experienced engineering team offers customized solutions tailored to your specific application requirements.
FAQ
Q: How do you manage the magnetic field around air core reactors?
A: Installation requires maintaining specific clearance distances from metallic structures to prevent eddy current heating. We provide detailed installation guidelines with each unit.
Q: Can these reactors be installed horizontally?
A: No, vertical mounting is required for proper natural air cooling through the winding ducts.
Q: What maintenance is required?
A: These reactors are virtually maintenance-free. Annual inspections for surface cleaning and connection tightening are recommended.
Q: How do noise levels compare to standards?
A: Our tension-controlled winding and rigid epoxy construction keep noise below 65dB, meeting environmental requirements.
Contact Us
Ready to enhance your power quality with our CKGKL Series Dry-Type Air Core Reactor? Contact our technical team today for detailed specifications and customized solutions. Email us at serina@xaxd-electric.com to discuss your project requirements and receive expert recommendations for optimal system performance.
