Capacitor for 10KV Passive Harmonic Filter

Capacitor for 10KV Passive Harmonic Filter

Product Introduction

When you're dealing with power quality issues in your 10kV electrical distribution system, our Capacitor for 10KV Passive Harmonic Filter provides the perfect solution. This specialized medium-voltage capacitor is engineered specifically for integration into tuned inductor-capacitor circuits. Unlike standard power factor correction capacitors, these units handle both fundamental voltage and the demanding thermal stresses from high-frequency harmonic currents. Your system will benefit from reduced Total Harmonic Distortion (THD) and improved power factor performance.

Our Capacitor for 10KV Passive Harmonic Filter addresses critical challenges including equipment failures caused by voltage spikes and utility penalties for poor power factor. You'll find these capacitors essential for maintaining grid stability while protecting your valuable electrical equipment.

Technical Specifications

Main Features and Advantages

You'll appreciate the advanced design features that set our capacitors apart. The all-film dielectric construction uses polypropylene impregnated with biodegradable synthetic fluids, ensuring high partial discharge inception voltages.

Superior Thermal Management: Extended aluminum foil designs provide excellent heat dissipation for your demanding applications.

Safety First: Internal discharge resistors reduce residual voltage to less than 50V within 5 minutes after disconnection.

Rugged Construction: Stainless steel casing withstands harsh outdoor environments and industrial conditions.

Precise Tuning: Tight capacitance tolerance ensures your filter maintains accurate harmonic frequency targeting.

Long Service Life: Designed for 15-20 years of reliable operation when properly maintained.

Practical Applications

Your industrial facility can benefit from our Capacitor for 10KV Passive Harmonic Filter in several critical applications:

Metallurgy & Electric Arc Furnaces: Steel manufacturing operations use these capacitors to absorb 2nd, 3rd, and 5th harmonics, preventing furnace trip-outs and stabilizing voltage during extreme operating conditions.

Water Treatment Facilities: Large pumps driven by medium-voltage Variable Frequency Drives create harmonic noise. Our capacitors prevent resonance that could damage motor windings and disrupt control systems.

Wind Farm Substations: As wind turbines feed into collector grids, inverters generate high-frequency switching harmonics. You need these capacitors for Grid Code compliance and stable operation.

Industrial Manufacturing: Any facility with non-linear loads like UPS systems, variable speed drives, or welding equipment will benefit from harmonic filtering.

How It Works

The Capacitor for 10KV Passive Harmonic Filter works by creating a low-impedance path for specific harmonic frequencies. When connected in series with a reactor, it forms a tuned circuit that resonates at predetermined harmonic frequencies.

This resonance effectively shunts harmonic distortion to ground before it can propagate through your electrical system. Simultaneously, the capacitor injects reactive power to improve your power factor and stabilize grid voltage.

The voltage rating exceeds the system voltage because the series reactor configuration creates voltage rise across the capacitor terminals. This Ferranti effect requires careful engineering to ensure reliable operation.

Manufacturing Excellence

At Xi'an Xidian Medium and Low Voltage Electric Co., Ltd., we follow strict quality control procedures. Every unit undergoes comprehensive testing including voltage tests, capacitance measurements, and partial discharge testing.

Our manufacturing process adheres to IEC 60871-1 and IEEE 18 standards. We've passed ISO9001 quality management, ISO14001 environmental management, and OHSAS18001 occupational health and safety certifications.

Quality inspection includes routine voltage tests at 2.15x rated voltage, precise capacitance tolerance verification, sealing tests at elevated temperatures, and surge endurance testing.

Why Choose Us

You can trust our expertise in medium and low voltage power distribution equipment. We offer over 100 varieties across 34 series, providing comprehensive system solutions for your specific needs.

Our products serve rated voltages from 0.4kV to 40.5kV with currents from 630A to 4000A. High-altitude variants meet requirements up to 4000m elevation.

We provide personalized technical support and customized solutions based on your unique application requirements. Our experienced engineering team ensures proper capacitor selection and system integration.

FAQ

Q: Why do you recommend higher voltage ratings than my 10kV system?

A: The series reactor creates voltage rise across capacitor terminals. We typically recommend 11kV or 12kV ratings depending on your tuning requirements.

Q: Can I use standard power factor capacitors instead?

A: No. Standard capacitors cannot handle harmonic currents and will fail quickly in harmonic-rich environments.

Q: How do I know if my capacitor needs replacement?

A: Watch for bulging cases, oil leakage, significant capacitance drops, or unbalance protection relay activation.

Q: What affects the expected lifespan?

A: Proper ventilation, staying within temperature limits, and avoiding harmonic overload ensure 15-20 year operation.

Contact Us

Ready to improve your power quality with our Capacitor for 10KV Passive Harmonic Filter? Our technical team is here to help you select the right solution for your specific application.

Contact us today at serina@xaxd-electric.com for detailed specifications, custom configurations, and technical support. We'll work with you to design the optimal harmonic filtering solution for your facility.
