Reactive & Harmonic Filter Capacitor

Reactive & Harmonic Filter Capacitor - Premium Power Quality Solution

Product Introduction

Looking for a reliable solution to improve your electrical system's power quality? Our Reactive & Harmonic Filter Capacitor is specifically engineered for networks with high harmonic distortion. Unlike standard power factor correction capacitors, this advanced component handles non-linear loads from VFDs, UPS systems, and LED lighting without overheating or failure. The Reactive & Harmonic Filter Capacitor provides dual functionality - reactive power compensation and harmonic filtering when paired with detuned reactors.

Your facility benefits from eliminated utility penalties, reduced equipment stress, and extended transformer life. This technology prevents dangerous harmonic resonance while maintaining optimal power factor. Perfect for industrial facilities, data centers, and renewable energy installations.

Technical Specifications

Main Features and Advantages

Advanced Dielectric Technology

Our capacitors use heavy-edge metallized polypropylene film with self-healing properties. This ensures reliable operation under high inrush currents up to 200 times rated current.

Enhanced Safety Systems

Integrated overpressure disconnectors provide fail-safe protection. These tear-off fuses physically isolate the capacitor during internal failures, preventing case rupture.

Superior Thermal Management

Gas-impregnated dry-type design maintains low operating temperatures. The maximized surface area design ensures excellent heat dissipation in demanding environments.

Harmonic Resilience

Built specifically for high Total Harmonic Distortion environments. Your Reactive & Harmonic Filter Capacitor won't fail like standard units when exposed to harmonic pollution.

Voltage Rise Compensation

Higher voltage ratings (480V, 525V, 690V) accommodate voltage increases from series reactors. This prevents overvoltage damage in detuned filter applications.

Practical Applications

Heavy Industry Operations

Steel mills and metallurgy plants with Electric Arc Furnaces benefit greatly. When paired with 5.67% or 7% detuned reactors, our capacitors filter substantial harmonic currents and prevent main breaker trips.

Data Centers and Telecommunications

High-density UPS systems create significant 3rd harmonic issues. Our solution maintains voltage stability while reducing HVAC heat loads through source-level power factor correction.

Renewable Energy Installations

Wind and solar inverters introduce switching harmonics into the grid. Deploy our capacitors at collection points to ensure grid code compliance for THDi and voltage regulation.

Manufacturing Facilities

Variable Frequency Drives in automation systems create power quality challenges. Our capacitors eliminate utility power factor penalties while protecting sensitive equipment.

How It Works

The Reactive & Harmonic Filter Capacitor operates on dual principles. First, it provides reactive power compensation, bringing your power factor close to 1.0. This reduces current flow and eliminates utility penalties.

Second, when combined with detuned reactors, it forms an LC filter circuit. This configuration targets specific harmonic orders - typically 5th, 7th, and 11th harmonics. The filter prevents resonance while absorbing harmonic currents.

The self-healing metallization automatically clears minor dielectric faults. This maintains capacitance values and extends service life significantly compared to standard units.

Manufacturing Excellence

Xi'an Xikai Medium and Low Voltage Electric Co., Ltd. brings decades of power distribution expertise to every unit. Our comprehensive product range covers 9 categories and 34 series of electrical equipment.

We maintain ISO9001 quality management certification alongside ISO14001 environmental and OHSAS18001 safety standards. Every capacitor meets national and industry standards with leading domestic performance levels.

Our manufacturing processes ensure consistent quality across rated voltages from 0.4kV to 40.5kV and currents from 630A to 4000A. High-altitude products perform reliably at elevations up to 4000m.

Why Choose Us

Proven Track Record

Our products serve major industrial facilities across multiple sectors. The reputation for reliability comes from rigorous testing and quality control processes.

Technical Support

Expert engineering support helps you select the right configuration. We provide system analysis and custom solutions for unique applications.

Compliance Assurance

All products strictly adhere to IEC 60831-1/2 and EN 60831 standards. This ensures safety, performance, and regulatory compliance in your installation.

Comprehensive Solutions

Beyond individual components, we offer complete system integration services. Our expertise covers the full spectrum of medium and low voltage power distribution.

FAQ

Q: What's the difference between standard and harmonic filter capacitors?

A: Standard capacitors fail in high-harmonic environments due to overheating and resonance. Our harmonic filter units have reinforced dielectric strength and thermal capabilities specifically for these conditions.

Q: Do I need reactors with these capacitors?

A: Yes, for harmonic filtering applications. Detuned reactors create the LC filter circuit that prevents resonance and targets specific harmonic frequencies.

Q: What harmonic orders can be filtered?

A: Typically 5th, 7th, and 11th harmonics depending on reactor selection. Common detuning percentages are 5.67%, 7%, and 14%.

Q: How do I determine the right capacity?

A: Our engineers analyze your load profile, existing power factor, and harmonic spectrum to recommend optimal sizing and configuration.

Q: What maintenance is required?

A: Minimal maintenance needed. Regular visual inspections and periodic capacitance measurements ensure continued performance.

Contact Us

Ready to improve your power quality with our Reactive & Harmonic Filter Capacitor solutions? Our technical team is here to help you select the right configuration for your specific application.

Contact our power quality specialists today for detailed technical consultation and custom solutions. We provide comprehensive support from initial assessment through installation and commissioning.

Email: serina@xaxd-electric.com

Let us help you eliminate power factor penalties, reduce equipment stress, and achieve optimal electrical system performance with proven harmonic filtering technology.
